The JCPT1614HA self-propelled 16m electric scissor lift is used for various repair and installation jobs. It is operated at construction sites, warehouses, factories and other facilities.
This device uses high-life Lithium batteries with 24V voltage and operates reliably. The working surface of 2.64m x 1.12m is designed to carry necessary goods for the operator.
JCPT1614HA stands out with its high mobility and resistance to wear and tear. The 16m electric scissor lift simplifies the significant lifting and lowering process.
UMAC Vietnam is the official distributor of Dingli man lift in Vietnam. We guarantee that our Dingli man lift are genuine, high-quality, and affordable.
Therefore, if you are in need of investing in a crane, please check out >> Dingli man lift on our website: www.umac.com.vn to see what models are available for sale.
Specification
Size
| Max. Working Height | 15.70m |
| Max. Platform Height | 13.70m |
| Overall Length | 2.84m |
| Overall Width | 1.39m |
| Overall Height(Rails Up) | 2.62m |
| Overall Height(Rails Down) | 2.09m |
| Platform Size(Length×Width) | 2.64m×1.12m |
| Platform Extension Size | 0.90m |
| Ground Clearance(Stowed/Raised) | 0.10m/0.019m |
| Wheelbase | 2.22m |
| Turning Radius(Inside/Outside) | 0m/2.70m |
| Tyres | φ381×127mm |
Performance
| S.W.L | 227kg |
| S.W.L On Extension | 113kg |
| Max. Occupants | 2 |
| Gradeability | 25% |
| Travel Speed(Stowed) | 3.5km/h |
| Travel Speed(Raised) | 0.8km/h |
| Max. Working Slope | X-1.5°/Y-3° |
| Up/Down Speed | 72/67sec |
Weight
| Overall Weight(Lead-acid Battery) | 3440kg |
| Overall Weight(Lithium Battery) | 3350kg |
Power
| Battery | 4×12V/240Ah |
| Charger | 24V/30A |
| Lifting Motor | 24VAC/3.5kW |
| Hydraulic Tank | 20L |
